Schneider Electric Acti9 iSW – 1-pole switch disconnector 32 A / 250 V

Order product

Delivery time approximately 2 weeks

Product code: A9S60132
EAN: 3606480088711
Brand: Schneider Electric

Product description

Schneider Electric's Acti9 iSW is a modular 1-pole switch disconnector suitable for control circuits and electrical installations where reliable isolation and protection are required. The high-quality construction ensures a long service life and reliable operation.

Features

• Brand/Series: Schneider Electric, Acti9 iSW

• Rated load current: 32 A
• Rated voltage: 250 V AC
• Number of poles: 1 pole (1P)
• Series category / intended use: Control switch disconnector
• Module width: 2 modules / 9 mm – rail modules
• Dimensions (H × W × D):
  – Height: 77 mm
  – Width: 18 mm
  – Depth: 70 mm (or ~75.5 mm)
• Mechanical durability: 300,000 operating cycles
• Electrical durability: 30,000 operating cycles

• Enclosure class / protection level: IP20 (and IP40 in enclosure)

• Control type / function: toggle switch

• Local indicator: ON/OFF indication (with indicator light, if available)

• Connection / terminal wiring: Tunnel-type terminals, max. 10 mm²
• Wire stripping length: 9 mm

• Tightening torque: 1.2 N m

• Standards: EN/IEC 60669-2-4 (switch disconnectors)
• Operating temperature: –20 °C … +50 °C
• Storage temperature: –40 °C … +70 °C

Features and benefits

• Modular design for DIN rail mounting

• Reliable disconnection function with one pole

• Long mechanical and electrical durability

• IP20 protection and possibility of additional information (IP40)

• Suitable for control systems and isolation of electrical installations

• Indicator light possible in switch versions (depending on version)
